Introduction

Open the Device Manager and select Human Interface Devices HID-compliant touch screen Action Enable device. If you do not see HID-compliant touch screen, select Action Scan for hardware changes. If touchscreen doesn’t work after enabling, right-click HID-compliant touch screen Update Driver. Search for driver update and install it. Solution 3: Reinstall the touchscreen driver. In the search box on the taskbar, type device manager, and then select Device Manager in the results. Expand the Human Interface Devices category. Right-click Intel(R) Precise Touch Device, select Uninstall device, and then, in the Uninstall Device.

The plpevtch driver is an eventdevice driver for touchscreens under Xorg 7.x.

Why another touchscreen driver when evtouch already exists? I was using evtouchon my Flybook with Xorg 6.9 very long. But with Xorg 7.3 it was not working for me. ShortlyI bought a touchscreen and I was not able to get it to work with evtouch. Then quickly Icreated this new driver and it works in the way I want. plpevtch is not a fork of evtouch.

Download

xf86-input-plpevtch-0.5.0.tar.gz (2010/05/25)

xf86-input-plpevtch-0.4.1.tar.gz (2010/04/17) SwapAxes added by Ken
xf86-input-plpevtch-0.4.0.tar.gz (2009/02/26)

Supported Hardware

I have only 2 different touchscreens, so i can only say that it works for those. Butthe driver should work with any other eventdev touchscreen kernel driver too.

The driver was successful tested on

USB Touchscreen eGalax (ID 0eef:0001 D-WAV Scientific Co., Ltd eGalax TouchScreen)
Flybook Touchscreen PenmountLPC

Configuration

Important: its required that the evdev kernel module is loaded or builtin in your kernel!

Unity Touchscreen Input

Here is a sample configuration for Xorg 7.x xorg.conf

add to the ServerLayout

How to calibrate

add Option ‘Calibrate’ to the touchscreen section
restart the X server
move along the borders of your touchscreen multiple times (ignore the mouse pointer). Its required to get the minimum and maximum values of your screen.
search /var/log/Xorg.0.log for the last ‘plpevdev’ and ‘Calibrate’. You will see something like
(II) touchscreen: Calibrate | MinX: 67 | MaxX: 1984 | MinY: 42 | MaxY: 1920
use this values in the touchscreen section of your xorg.conf
remove the Calibrate Option in the touchscreen section
restart the X server

Install

If your Xorg is installed in /usr/X11R7 then run
./configure — prefix=/usr/X11R7 && make && make install

If your Xorg is installed in /usr then run
./configure — prefix=/usr && make && make install

→

This is to test the type of touch input that falls into the category of Custom Gestures for a Windows Touchscreen device. This test also checks the 3rd party driver dependencies for the Touchscreen device.

Test names

Other.jsonAssociated compatibility requirements

Device.Input.Digitizer.Touch.CustomGestures
Device.Input.Digitizer.Base.ThirdPartyDrivers
Device.Input.Digitizer.Base.HIDCompliant

Test purpose

Touchscreen Device Manager Windows 10

Verifies that a Windows Touchscreen device meets the custom gestures and third party driver requirements.Tools required

None.Running the test

Touchscreen Input Device

The Windows Touch Test combines a set of simple manual tests. The requirements that are tested, include the absence of third party drivers, the absence of custom touch gestures, and the allowed physical dimensions of the device.

Hid Compliant Touchscreen Device Driver

Command syntax

Other.jsonPassing criteria
